Couplings can be made available to the extent appropriate for Standard shaft diameters. Although the places where the clutches are used vary, it would not be wrong to say that we can see the clutches wherever mile-to-mile motion transmission is concerned.



Characteristics of clutches

There is no difference in basic principle between decouchable-connectable clutches and brakes. It is intended to bring two different parts to the same speed with clutches, while it is desirable to bring the rotating side to the speed of the non-rotating side in the brakes, that is, to stop. There is a great similarity between many decoupage brakes and clutches



Types of clutches

Classification of clutches can be done as follows:



Types of clutches by structure









we can generally diversify the clutches according to their structure and according to the type of control separately.



1- TIGHT CLUTCHES

They are clutches that do not dissolve when transmitting movement from one shaft to another.



1-a Bracelet grip

Its outer parts are in the form of two conical half-sleeves, which are joined by bringing the shafts end to end. To hold these two halves of the sleeve, bracelets are passed out of the sleeves from both sides so that the grip is tightened. It is widely used because it is easy to install and disassemble. It is preferred in humid places.



clutch ring grip types

1-b Sleeve clutch:

Two shafts with a wedge slot are brought to the end of the end and a sleeve is put on it. Inclined wedges with a nose are fixed by tapping. Protective hair splinters are attached from two sides.



sleeve coupling

1-c Sleeve Grip:

In this type of clutch, which is made of two bowl-shaped parts, called a sleeve clutch, the shafts are brought to the end and the sleeves are attached. It is tightened with bolts and nuts. To avoid accidents, round hair is passed around it.



sleeve grip

1-d Flanged couplings:

plate-shaped flanges with bolt holes around them are attached to the shaft ends in hot form or by hydraulic fitting. For centering dec, two-piece bracelets are placed between the flanges and tightening is performed with bolts and nuts. Gaskets are installed in places where decoupage is important.



types of couplings flanged coupling 3d

1-e Sellers clutch:

In this type of clutch, two conical sleeves are pulled with three long bolts inside a cylinder and the shafts are brought end to end. Since the bolts pass through the sleeves and the cylinder, the coupling parts are prevented from rotating.



Sellers the taper in the clutch is 1: 10 to 1: 20.



sellers grip

1-f Forehead grip:

It is used for gripping hollow shafts by opening threads similar to a screw thread on the forehead parts of the coupling parts. The couplings are clamped by bringing the coupling parts closer together.
